JH6000D-4 Comprehensive detector
  • JH6000D-4 Comprehensive detector

JH6000D-4 Comprehensive detector

recommendation index:
Detection components, high accuracy, good stability
Portable design, fast testing, low air consumption, environmentally friendly
Automatic flow control, efficient and accurate, effectively reducing sample gas emissions
Automatic judgment of detection endpoints, suitable for different places
  • Detect the main products of cracking of insulating materials inside SF6 electrical equipment: SO2, SOF2, H2S, CO, HF, H2 content (H2 is optional)

name

component

parameter

minimum detectable quantity

SO2+SOF2H2S、HF

≤0.1μL/L

CO/H2

≤0.5μL/L

purity

≤0.03%(V/V)

Dew point: resistance capacitance

≤0.1℃

precision

SO2+SOF2H2S、HF

measurement value≤ 10 μL/L, error ≤ ± 0.5 μL/L

measured value > 10 μL/L, error  ± 5%.

CO/H2

measurement value ≤ 50 μL/L, error ≤ ± 2.0 μL/L

measurement value > 50 μL/L, error ≤ ± 4%

purity

≤±0.1 %(W/W)

resistance capacitance/mirror

≤±1℃/±0.3℃

repeatability

SO2+SOF2 、H2S、HF

measured value  ≤ 10 μL/L, ≤ 0.2 μL/L

10μL/L~100μL/L:2%.

CO/H2

measured value is ≤ 50 μL/L, ≤ 1.5 μL/L

detection value 50 μL/L ~1000 μL/L: ≤ 3%

purity

≤0.05%(W/W)

resistance capacitance/mirror

1%(RSD)

range

SO2+SOF2

0~100μL/L,0~2000μL/L

H2S

0~100μL/L

HF

0~20μL/L

CO/H2

0~1000μL/L

purity

0~100%

resistance capacitance/mirror

-80℃~+20℃/-60℃~+20℃@30℃


Related recommendations

JHPD-20, Portable Partial Discharge Tester

Good quality, high sensitivity, high cost performance

JHPD-200 Switchgear partial discharge detector

Handheld equipment, light weight, easy to carry, easy to inspect

JHPD-500 Multifunctional Partial Discharge Detector
